Model 14F__T Roller Conveyor Product Information

The Model 14F__T roller conveyor is constructed of 4"x7ga Painted Steel side channels and butt plate couplers. 14F__T rollers are heavy duty and can conveyor heavy loads, making them one of if not the most popular handling systems around.



14F__T Roller Conveyor Construction:

Roller: Model T
Tube: 2-5/8"x7ga Plain Stl
Axle: 11/16" Hex Plain Stl
Roller Bearing: Commercial Light Oil
Axle retention: Spring Retained
Frame: 14F: 4"x7ga Painted Steel side channels
Coupling: Butt Plate
Roller Capacity (lbs): 587 to 850
Frame Capacity (lbs/ft): 230 on 10' support centers, 1,050 on 5' centers



14F__T Roller Conveyor Configuration:

Roller Centers (in): 3, 4.5, 6
Between Frame (in): 7 to 51
Straights (ft): 5, 10
Curves (deg): 45, 90
Sleeve: none online

FILTERS
642 results
Roller Conveyor 14F05S06B33BP

14F05S06B33BP

Roller Conveyor 14F05S06B31BP

14F05S06B31BP

Roller Conveyor 14F05S06B27BP

14F05S06B27BP

Roller Conveyor 14F05S06B23BP

14F05S06B23BP

Roller Conveyor 14F05S06B22BP

14F05S06B22BP

Roller Conveyor 14F05S06B21BP

14F05S06B21BP

Roller Conveyor 14F05S06B19BP

14F05S06B19BP

Roller Conveyor 14F05S06B17BP

14F05S06B17BP

Roller Conveyor 14F05S06B16BP

14F05S06B16BP

Roller Conveyor 14F05S06B15BP

14F05S06B15BP

Roller Conveyor 14F05S06B13BP

14F05S06B13BP

Roller Conveyor 14F05S06B10BP

14F05S06B10BP

Roller Conveyor 14F05S06B07BP

14F05S06B07BP

Roller Conveyor 14F05S03B51BP

14F05S03B51BP

Roller Conveyor 14F05S03B47BP

14F05S03B47BP

Roller Conveyor 14F05S03B43BP

14F05S03B43BP

Roller Conveyor 14F05S03B39BP

14F05S03B39BP

Roller Conveyor 14F05S03B37BP

14F05S03B37BP

Roller Conveyor 14F05S03B33BP

14F05S03B33BP

Roller Conveyor 14F05S03B27BP

14F05S03B27BP

Roller Conveyor 14F05S03B25BP

14F05S03B25BP

Roller Conveyor 14F05S03B23BP

14F05S03B23BP

Roller Conveyor 14F05S03B22BP

14F05S03B22BP

Roller Conveyor 14F05S03B21BP

14F05S03B21BP

Roller Conveyor 14F05S03B17BP

14F05S03B17BP

Roller Conveyor 14F05S03B16BP

14F05S03B16BP

Roller Conveyor 14F05S03B15BP

14F05S03B15BP

Roller Conveyor 14F05S03B13BP

14F05S03B13BP

Roller Conveyor 14F05S03B10BP

14F05S03B10BP

Roller Conveyor 14F05S03B07BP

14F05S03B07BP
